Description
| Part number | 6151590120 | |
| Model | CP6120-D35H | |
| Handle type | D-Handle Inside Trigger | |
| Square drive | 1 1/2″ | |
| Working Torque Range (fwd) | 815-2,710 Nm | |
| Maximum Torque (reverse) | 4880 Nm | |
| Free speed | 3500 rpm | |
| Blows per minute | 960 | |
| Net weight | 15.65 kg | |
| Length | 420 mm | |
| Side to center | 54 mm | |
| Actual air consumption | 28.3 l/s | |
| Free speed air consumption | 51.5 l/s | |
| Air inlet thread size | 0.5 ” | |
| Min. hose size | 19 mm | |
| Sound pressure | 97 db(A) | |
| Sound Power | 108 db(A) | |
| Vibration α (ISO-28927-2) | 21.8 m/s² | |
| Vibration K (ISO-28927-2) | 11.8 m/s² | |
| Socket retainer | Hole | |
| Clutch type | 2-jaw clutch | |
| Box dimensions | 505x240x145 |
